OpenKh Tool Documentation - KH2 Mods Manager

This document will focus on teaching you how to create mods using the OpenKH Mods Manager

Creating a mod

A well produced mod should contain the following

mod.yml - The format of which is explained below
icon.png - A 128x128 image which will be seen in the mods list
preview.png - A image of maximum size 512 px wide by 288 px tall, which will be shown in the mod description on the right
Other files - whatever files are needed for the mod, as defined by the mod.yml

The mod.yml file is a YAML format specification for your mod. It will contain the following fields

title - The title of your mod, as displayed in the mods manager
description - A description of what your mod does
originalAuthor - The name of the original author who created this mod. If you just ported this mod to the modsmanager for someone else, include the original authors name.
logo - The path to the icon.png
assets - A list of assets that will be modified when the mod runs. See asset types, for details on creating an asset. Some asset types will work on any game, while others are game specific.

While you are developing a mod you can create a folder inside the “mods” directory of the mods manager release, IE

<modsmanager release>/mods/<authorname>/<modname>

Asset Methods

copy (any game) - Performs a direct copy to overwrite a file. Works on any file type.

Asset Example:

- method: copy
  name: msn/jp/BB03_MS103.bar
  source:
  - name: files/modified_msn.bar

binarc (KH2) - Specifies a modification to a subfile within a binarc, using one of the available methods. See binarc methods for details on implementing a specific method.

Asset Example

- method: binarc
  name: ard/wi03.ard
  source:
  - method: spawnpoint
    name: b_40
    source:
    - name: files/b_40.yml
    type: AreaDataSpawn

Binarc Methods

copy (KH2) - Performs a copy on a supfile within a Bar. Must be one of the following types

Asset Example

- method: binarc
  name: msn/jp/HB01_MS601.bar
  source:
  - method: copy
    name: ms_b
    source:
    - name: he_c.bdx
    type: Bdx

imgd (KH2) - Replaces a single imgd found within a binarc

Asset Example

  - name: menu/us/title.2ld
    multi:
      - name: menu/jp/title.2ld
    required: true
    method: binarc
    source:
      - name: titl
        type: imgd
        method: imgd
        source:
          - name: title/title1.png
            highdef: title/title1_hd.png

// imgz // fac (KH2) - Replaces multiple imgd’s found within a binarc.

Asset Example

  - name: menu/us/title.2ld
    multi:
      - name: menu/jp/title.2ld
      - name: menu/uk/title.2ld
      - name: menu/it/title.2ld
      - name: menu/sp/title.2ld
      - name: menu/gr/title.2ld
      - name: menu/fr/title.2ld
      - name: menu/fm/title.2ld
    required: true
    method: binarc
    source:
      - name: titl
        type: imgz
        method: imgz
        source:
          - name: title/title1.png
            highdef: title/title1_hd.png
            index: 1

kh2msg (KH2) - Replaces text found within a kh2 messages file. Uses a yaml file as an source.

Asset Example

  - name: msg/jp/sys.bar
    method: binarc
    source:
      - name: sys
        type: list
        method: kh2msg
        source:
          - name: sys.yml
            language: jp

Yaml Source Example

- id: 0x432e
  en: OpenKH is awesome!
  it: OpenKH è incredibile!
  sp: ¡OpenKH es increíble!
  gr: OpenKH ist großartig!
  fr: OpenKH est incroyable!
  jp: OPENKHすばらしい!

areadatascript (KH2) - Modifies a series programs found within a KH2 Spawnscript subfile (located within ard files), using the text format created by OpenKh.Command.SpawnScript. You can only provide a subset of the programs found within the spawnscript, the others will be taken from the original file.

Asset Example

- method: binarc
  name: ard/hb34.ard
  source:
  - method: areadatascript
    name: evt
    source:
    - name: files/hb34/program-87
    - name: files/hb34/program-7c
    - name: files/hb34/program-7d
    - name: files/hb34/program-86
    type: AreaDataScript

Text Source Example

Program 0x7C
Party DEFAULT
Bgm Default Default
AreaSettings 0 -1
	SetJump Type 2 World HB Area 0 Entrance 0 LocalSet 151 FadeType 1
	SetPartyMenu 0

areadataspawn (KH2) - Modifies a KH2 Spawnpoint subfile (located within ard files), using an yaml file created using OpenKh.Command.SpawnScript.

Asset Example

- method: binarc
  name: ard/wi03.ard
  source:
  - method: spawnpoint
    name: b_40
    source:
    - name: files/b_40.yml
    type: AreaDataSpawn

listpatch (KH2) - Can modify the following different types of list binaries found within KH2.
trsr
cmd
item
sklt
enmp
fmlv
lvup
bons
atkp
przt
magc
objentry

Asset Example

- name: 00battle.bin
  method: binarc
  source:
  - name: fmlv
    method: listpatch
    type: List
    source:
      - name: FmlvList.yml
        type: fmlv

trsr Source Example

2:
  ItemId: 347

cmd Source Example

- Id: 1
  Execute: 3
  Argument: 3
  SubMenu: 1
  CmdIcon: 3
  MessageId: 33249
  Flags: Cursor, InBattleOnly
  Range: -1
  Dir: 0
  DirRange: -1
  Cost: 0
  CmdCamera: 0
  Priority: 100
  CmdReceiver: 0
  Time: 0
  Require: 0
  Mark: 1
  CmdAction: 0
  ReactionCount: 0
  DistRange: 0
  Score: 0
  DisableForm: 63552
  Group: 2
  Reserve: 0

item Source Example

Stats:
- Ability: 412
  AbilityPoints: 0
  Attack: 0
  DarkResistance: 100
  Defense: 0
  FireResistance: 100
  GeneralResistance: 100
  IceResistance: 100
  Id: 116
  LightningResistance: 100
  Magic: 7
  Unknown: 0
  Unknown08: 100
  Unknown0d: 100
Items:
- Id: 1
  Type: Consumable
  Flag0: 0
  Flag1: 40
  Rank: C
  StatEntry: 1
  Name: 33528
  Description: 33529
  ShopBuy: 40
  ShopSell: 10
  Command: 23
  Slot: 0
  Picture: 1
  Icon1: 9
  Icon2: 0

sklt Source Example

- CharacterId: 1
  Bone1: 178
  Bone2: 86

enmp Source Example

- Id: 0
  Level: 1
  Health:
  - 1
  - 1
  - 1
  - 1
  - 1
  - 1
  - 1
  MaxDamage: 1
  MinDamage: 1
  PhysicalWeakness: 1
  FireWeakness: 1
  IceWeakness: 1
  ThunderWeakness: 1
  DarkWeakness: 1
  LightWeakness: 1
  GeneralWeakness: 1
  Experience: 1
  Prize: 1
  BonusLevel: 1

fmlv Source Example

Final:
- Ability: 578
  Experience: 12
  FormId: 5
  FormLevel: 1
  GrowthAbilityLevel: 1

lvup Source Example

Sora:
  2:
    Ap: 0
    Character: Sora
    Defense: 0
    Exp: 100
    Level: 2
    Magic: 0
    Padding: 0
    ShieldAbility: 577
    StaffAbility: 577
    Strength: 0
    SwordAbility: 577

bons Source Example

2:
  Sora:
    AccessorySlotUpgrade: 0
    ArmorSlotUpgrade: 0
    BonusItem1: 99
    BonusItem2: 0
    CharacterId: 1
    Description: ''
    DriveGaugeUpgrade: 0
    HpIncrease: 0
    ItemSlotUpgrade: 0
    MpIncrease: 0
    RewardId: 2
    Unknown0c: 0

atkp Source Example

- Id: 0 #Hitbox 0
  SubId: 3
  Type: 1
  CriticalAdjust: 0
  Power: 25
  Team: 0
  Element: 0
  EnemyReaction: 0
  EffectOnHit: 2
  KnockbackStrength1: 32767
  KnockbackStrength2: 0
  Unknown: 0000
  Flags: BGHit, LimitPAX, Land, CapturePAX, ThankYou, KillBoss #Every possible AttackFlag shown
  RefactSelf: 0
  RefactOther: 0
  ReflectedMotion: 0
  ReflectHitBack: 0
  ReflectAction: 0
  ReflectHitSound: 0
  ReflectRC: 0
  ReflectRange: 0
  ReflectAngle: 0
  DamageEffect: 0
  Switch: 1
  Interval: 1
  FloorCheck: 1
  DriveDrain: 1
  RevengeDamage: 1
  AttackTrReaction: 1
  ComboGroup: 1
  RandomEffect: 1
  Kind: ComboFinisher
  HpDrain: 15

przt Source Example

- Id: 1
  SmallHpOrbs: 0
  BigHpOrbs: 1
  BigMoneyOrbs: 1
  MediumMoneyOrbs: 1
  SmallMoneyOrbs: 1
  SmallMpOrbs: 1
  BigMpOrbs: 1
  SmallDriveOrbs: 0
  BigDriveOrbs: 1
  Item1: 1
  Item1Percentage: 1
  Item2: 0
  Item2Percentage: 0
  Item3: 0
  Item3Percentage: 0

magc Source Example

- Id: 0
  Level: 3
  World: 1
  FileName: magic/FIRE_3.mag
  Item: 21
  Command: 120
  GroundMotion: 56
  GroundBlend: 2
  FinishMotion: 57
  FinishBlend: 2
  AirMotion: 58
  AirBlend: 2
  Voice: 7
  VoiceFinisher: 11
  VoiceSelf: -1

objentry Source Example

4:
  ObjectId: 4
  ObjectType: ZAKO
  SubType: 0
  DrawPriority: 0
  WeaponJoint: 0
  ModelName: M_EX520
  AnimationName: M_EX520.mset
  Flag: 8
  TargetType: 1
  Padding: 0
  NeoStatus: 1006
  NeoMoveset: 0
  Weight: 100
  SpawnLimiter: 8
  Page: 1
  ShadowSize: 1
  CommandMenuOption: Default
  SpawnObject1: 0
  SpawnObject2: 0
  SpawnObject3: 0
  SpawnObject4: 0

An example of a fully complete mod.yml can be seen below, and the full source of the mod can be seen here

title: OpenKH mod template
originalAuthor: OpenKH open-source assets
description: An example of mod to use as a template
assets:
  - name: menu/us/title.2ld
    multi:
      - name: menu/jp/title.2ld
      - name: menu/uk/title.2ld
      - name: menu/it/title.2ld
      - name: menu/sp/title.2ld
      - name: menu/gr/title.2ld
      - name: menu/fr/title.2ld
      - name: menu/fm/title.2ld
    required: true
    method: binarc
    source:
      - name: titl
        type: imgz
        method: imgz
        source:
          - name: title/title1.png
            highdef: title/title1_hd.png
            index: 1
  - name: msg/jp/sys.bar
    method: binarc
    source:
      - name: sys
        type: list
        method: kh2msg
        source:
          - name: sys.yml
            language: jp
  - name: msg/us/sys.bar
    method: binarc
    source:
      - name: sys
        type: list
        method: kh2msg
        source:
          - name: sys.yml
            language: en
  - name: msg/it/sys.bar
    method: binarc
    source:
      - name: sys
        type: list
        method: kh2msg
        source:
          - name: sys.yml
            language: it

Publishing a mod

Mods should be published to a public github repository, so that users an install the mod just by providing the repository name.

It is recommended to apply the following tags to the repository, in order to make it easily found by searching GitHub for mods manager mods.

openkh-mods

<your games abbreviation> (ie kh2 or bbs)
